Raimondi MRT84
|
|
|
Jib Radius: 51Mts
Max SWL: 5 Tonne
Max SWL @ Jib End: 1.25 Tonne
Height under Hook: 39.4Mts
Undercarriage: 3.8/4.4Mts
Total Power: 23/31 Kw
|
|
|
|
|
|
|
|
|
Raimondi MRT111
|
|
|
Jib Radius: 50Mts
Max SWL: 8 Tonne
Max SWL @ Jib End: 2.2 Tonne
Height under Hook: 46.2Mts
Undercarriage: 4.5/5.3Mts
Total Power: 37/43 Kw
|
|
|
|
|
|
|
|
|
Raimondi MR153
|
|
|
Jib Radius: 63Mts
Max SWL: 8 Tonne
Max SWL @ Jib End: 1.45 Tonne
Height under Hook: 43.4Mts
Undercarriage: 4.5/5.4Mts
Total Power: 38/44/57Kw
|
|
|
|
|
|
|
|
|
Liebherr 154ECH
|
|
|
Jib Radius: 60Mts
Max SWL: 10 Tonne
Max SWL @ Jib End: 1.4 Tonne
Height under Hook: 49Mts
Undercarriage: 4.6Mts
Total Power: 58/67 Kw
|
|
|
|
|
|
|
|
|
Comedil CTT181
|
|
|
Jib Radius: 65Mts
Max SWL: 8 Tonne
Max SWL @ Jib End: 1.9 Tonne
Height under Hook: 67.2Mts
Undercarriage: 4.5Mts
Total Power: 70 Kw
|
|
|
|
|
|
|
|
|
Liebherr 200EC-H
|
|
|
Jib Radius: 66Mts
Max SWL: 10 Tonne
Max SWL @ Jib End: 2.3 Tonne
Height under Hook: 66.6Mts
Undercarriage: 6Mts
Total Power: 68/76/96 Kw
|
|
|
|
|
|
|
|
|
Raimondi MRT36
|
|
|
Jib Radius: 35Mts
Max SWL: 4 Tonne
Max SWL at Jib End: 1.0 Tonne
Hook Height: 33.1Mts
Total Installed Power: 11.5/16KW
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Air Hoist
|
|
|
Used for similar applications as electric hoists |
|
|
|
|
|
|
|
|
Tirfor
|
|
|
Lifting and pulling machines. Available in range 0.8, 1.6, and 3.2 Tonne |
|
|
|
|
|
|
|
|
|
|
|
Beam Clamp
|
|
|
Adjustable beam clamp can be used as a fixed lifting point for a range of girders and required weights |
|
|
|
|
|
|
|
|
|
|
|
Jib Cranes
|
|
|
A jib crane is often the most ideal unit for manufacturing cells, small workshops, or facilities where space is limited.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Concrete Skip 1016
|
|
|
Horizontal conical shape with straight outlet and hose coupling, extra rugged heavy-duty design. Optionally with geared operation of the patented discharge gate, and lift beam.
|
|
|
|
|
|
|
|
|
Concrete Skip 1018
|
|
|
Horizontal conical shape with straight outlet and hose coupling, extra rugged heavy-duty design. Optionally with geared operation of the patented discharge gate, and lift beam.
|
|
|
|
|
|
|
|
|
Concrete Skip 1021
|
|
|
Round shape with lateral outlet, rugged heavy-duty design. Optionally welded on chain or lift beam.
|
|
|
|
|
|
|
|
|
Concrete Skip 1025
|
|
|
Horizontal round shape with lateral outlet, rugged heavy-duty design with geared operation.
Optionally with welded on chain or lift beam.
|
|
|
|
|
|
|
|
|
Concrete Skip 1028
|
|
|
Oval shape with lateral outlet for casting formwork. Rugged heavy-duty design with welded-on chain or lift beam.
|
|
|
|
|
|
|
|
|
Concrete Skip 1039
|
|
|
Horizontal shape with lateral outlet for casting formwork, rugged heavy-duty design. Optionally with lift beam or welded on chain.
|
|
|
|
|
|
|
|
|
|
|
|
Bulk Skip 1046
|
|
|
With crane lugs for attaching a 4-leg crane sling; stackable, heavy-duty and rugged design
Available with removable lid.
|
|
|
|
|
|
|
|
|
Pall Skip 1047
|
|
|
Bulk material skip with crane lugs for attaching a 4-leg crane sling; stackable with snap hooks; rugged heavy-duty design; stackable.
Available with removable lid.
|
|
|
|
|
|
|
|
|
Concrete Skip Twin Flow 1091
|
|
|
Square low shape with rounded corners, straight or lateral outlet and moveable flow control chute light-duty design with discharge gate optionally welded on chain or lift beam.
|
|
|
|
|
|
|
|
|
Muck Tipping Skip Circular 1224
|
|
|
With fold-down hanger and safety lock.
When the safety lock is opened by hand the tub empties automatically in response to the center of gravity of the hanger.
|
|
|
|
|
|
|
|
|
|
|
Muck Skip/Boat Skip 1045
|
|
|
With drop-down lift beam, hook ring and latch for automatic emptying of the skip without an assistant. |
|
|
|
|
|
|
|
|
|
|
|
|
|
Concrete Skip 1020
|
|
|
Designed for universal use, with a straight or lateral outlet and moveable flow control chute |
|
|
|
|
|
|
|
|
|
|
|
|
|
Static Crane Forks 1051
|
|
|
Simple yet rugged steel construction with pre-defined useful height and fixed prong spacing. |
|
|
|
|
|
|
|
|
Crane Forks Adjustable 1052
|
|
|
With infinitely adjustable by spindle guide from 540 to 900 mm, working height adjustable by pin system from 1150 to 1750 mm |
|
|
|
|
|
|
|
|
Crane Forks Adjustable 1053
|
|
|
Width infinitely adjustable manually from 450 to 950 mm, working height adjustable by pin system from 1150 to 1750 mm |
|
|
|
|
|
|
|
|
Crane Forks Adjustable 1054
|
|
|
Automatic weight compensation by com-pression spring. Ball-bearing, maintenance-free steel roller guide in top section.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Caged Crane Forks 1059
|
|
|
Automatic weight compensation by compression spring. Ball-bearing, maintenance-free steel roller guide in top section.
|
|
|
|
|
|
|
|
|
Brick Barrow 1104
|
|
|
For the transportation of all types of blocks at the building site.
|
|
|
|
|
|
|
|
|
Shackles
|
|
|
Available in Blue Pin, Green Pin, Dee and Bow |
|
|
|
|
|
|
|
|
Single Layer Block Grab
|
|
|
The heavy duty 1-2L block grab will handle one layer of concrete blocks (block size 440 x 215 x100mm) stacked on end or two layers stacked on edge. |
|
|
|
|
|
|
|
|
Vicario OMV331
|
|
|
This crane can lift 700kgs at a jib length of 20mts and a hook height of 16.8mts. It can lift 1800kgs at 8.94mts. |
|
|
|
|
|
|
|
|
Vicario OMV350
|
|
|
Capable of lifting 850kgs at 27mts jib length and 23mts hook height. Max capacity of 2200kgs at a jib length of 12.13mts |
|
|
|
|
|
|
|
|
Vicario OMV300
|
|
|
At a hook height of 22mts and a jib length of 36mts this crane can lift 1000kgs. At a jib length of 11.4mts the capacity of this crane is 4000kgs |
|
|
|
|
|
|
|
|
Vicario OMV340
|
|
|
This crane can lift 1050kgs at a jib length of 41.8mts and a hook height of 25mts. The max capacity at 13.35mts is 4000kgs |
|
|
|
|
|
|
|
|
Raimondi MR183 GR4
|
|
|
We currently have three used Raimondi MR183GR4 Tower Cranes for sale. For full technical details click the link below. If you wish to get further details please contact our Killarney or Dublin Depot |
|
|
|
|
|
|
|
|
FERRIN CRANE
|
|
|
Ferrin af-275 self erect crane
Year of manufacturer: 2000
27 m jib
11.9 under hook height
2000 kg max
800kg jib end
Up to date cert
Crane can be seen in use.
|
|
|
|
|
|
|
|
|
Mantis 35-10 Self Erect Crane
|
|
|
Mantis 35-10 Self Erect Crane
Year of manufacturer: 2003
35 m jib
23.3 under hook height
4000 kg max
1000kg jib end
Up to date cert
Crane can be seen in use.
|
|
|
|
|
|
|
|
 |
